| Nominal voltage | 220|240 V |
|---|---|
| Voltage type | AC/DC |
| Max. system power | 35 W |
| Max. number of luminaires per miniature circuit breaker B16 (MCB) | 21 |
| Max. number of luminaires per miniature circuit breaker C16 (MCB) | 35 |
| Power factor | 0.9 |
| Max. inrush current | 41.00 A |
| Inrush time | 150.0 |
| Displacement factor (DF) | ≥ 0.9 |
| Max. number of luminaires per miniature circuit breaker C10 (MCB) | 21 |
| Max. number of luminaires per miniature circuit breaker C13 (MCB) | 28 |
| Nominal voltage DC | 180|280 V |
| Frequency | 50|60 Hz |
| Colour temperature | 4000 K |
|---|---|
| Rated luminous flux according to IEC 62722-2-1 | 4200 lm |
| Luminaire efficacy | 120 lm/W |
| Equivalent to | CFL 1x55W |
| Colour consistency (SDCM) | 3 |
| Colour rendering index (CRI) | > 80 |
| CIE Flux Code | 60 86 97 100 100 |
| Beam angle | 90° |
|---|---|
| UGR | 19 |
| Lifetime (L70) | 70000 h |
|---|---|
| Lifetime (L80) | 60000 h |
| On-/Off-cycles | 100000 |
| Lifetime (L90) | 50000 h |
| Dimmability | BLE2 |
|---|
| Protection class | II |
|---|---|
| Degree of protection (IP) | IP20 |
| Impact strength | IK02 |
| Glow wire test | 650°C |
| Risk group (EN 62471) | RG0 |
| Type of control gear | LED operating device current-controlled |
|---|---|
| With control gear | Yes |
| Driver failure rate (at 5,000 hrs) | 1.0% |
| 230V Cable length | 1.0 m |
| Wirethrough | No |
| Housing colour | White |
|---|---|
| Optical material | PMMA |
| Cover material | Polycarbonate |
| Finishing | White RAL9016 |
| Length | 595 mm |
|---|---|
| Width | 595 mm |
| Height/depth | 100 mm |
| Application temperature | 25°C |
|---|---|
| Storage environment | -25|50°C |
| Operating temperature | -10|40°C |
| EAN code | EU HS Code | Packaging | Amount | Size (L x W x H) | Weight |
|---|---|---|---|---|---|
| 06931783010310 | 94051190 | CT | 1 | 0.64 x 0.645 x 0.135 m | 6.17 KG |
Accessory Safety cable ceiling kit - 500mm - Stainless steel
Accessory Panels - Frame 644mm x 644mm - White
Accessory Indoor - Junction box - White
Accessory Smart Lighting - Sensor surface module - White
Accessory Smart Lighting - Sensor recessed - Microwave (MW)
Accessory Smart Lighting - Sensor recessed - Passive Infrared (PIR)
Accessory Smart Lighting - Multi switch module
